Universal Plastic Mixer SH-003 - SH-006｜Vertical Plastic Material Mixer
Shuen Li Universal Plastic Mixer SH-003 - SH-006 is suitable for mixing plastic pellets, recycled materials, color masterbatch and additives. The vertical mixer design supports a wide range of plastic material blending applications for injection molding, extrusion, blow molding and plastic processing lines, helping improve material consistency, feeding stability and production preparation efficiency.
Universal Plastic Mixer
Universal Plastic Mixer SH-003, SH-006
Mixer Series
Universal Plastic Mixer
SH-003 - SH-006
Product Feature
The removable stirring blades are easy to dismantle.
8 blade design allows the material at the bottom of the tank to be mixed uniformly.
Material tank is manufactured from stainless steel (SUS304).
Equipped with a timing switch.
Specification
| CE Model | Unit | SH-003 | SH-004 | SH-005 | SH-006 |
|---|---|---|---|---|---|
| Motor | hp | 3 | 5 | 7.5 | 10 |
| Capacity | kg/hr | 50 | 100 | 150 | 200 |
| Weight | kg | 130 | 160 | 200 | 300 |
| Dimension | mm | 1180x1180x1390 | 1240c1240x1450 | 1350x1350x1570 | 1430x1430x1620 |
